TA-T Series Oversized Base Pedestals
220mm Base • Interlocking Tie-Rod System

TA-T Series Pedestals

Engineered for extreme elevations and critical safety. Featuring a massive 220mm base and an exclusive lateral tie-rod system that locks adjacent pedestals together into a rigid, sway-proof structural grid.

Extreme Stability
TA-T Series Specifications

Technical Specifications

  • ModelTA-T Series (Ultimate Stability)
  • Height Range180 mm — 1210 mm
  • Bearing Weight1200 ~ 2000 KG
  • Head / Base Dia.150 mm / 220 mm
  • Exclusive FeatureLateral Tie-Rod System (Connects and locks adjacent pedestals to eliminate structural sway).
  • Core AdvantageDual-action stability: The 220mm oversized base resists rollover, while the tie-rods neutralize lateral shear forces in extreme high-span conditions.
Engineering Excellence

Dual-Action Stability System

Why structural engineers trust the TA-T series for extreme high-span architectures.

Lateral Tie-Rod System Installation
Interlocking Grid Setup

220mm Oversized Base

Expands the ground contact area exponentially compared to standard 200mm bases, acting as a massive anchor to prevent vertical tipping and rollover.

Lateral Tie-Rod System

The exclusive cross-bracing design allows adjacent pedestals to interlock horizontally. This neutralizes lateral shear forces and eliminates dangerous sway.

Rigid Structural Grid

Transforms individual supports into a unified, high-rigidity structural framework. The ultimate insurance for installations reaching up to 1210mm in height.

TA-T Series Matrix

Select quantities for your extreme elevation needs and add them to your Quote List instantly.

TA-T0-01

180-320mm
Est. Qty

TA-T0-02

230-370mm
Est. Qty

TA-T0-04

290-420mm
Est. Qty

TA-T1-01

340-520mm
Est. Qty

TA-T1-02

390-570mm
Est. Qty

TA-T1-03

440-620mm
Est. Qty

TA-T2-01

460-720mm
Est. Qty

TA-T2-02

510-770mm
Est. Qty

TA-T2-03

560-820mm
Est. Qty

TA-T3-01

580-920mm
Est. Qty

TA-T3-02

630-970mm
Est. Qty

TA-T3-03

680-1020mm
Est. Qty

TA-T4-01

700-1120mm
Est. Qty

TA-T4-02

750-1170mm
Est. Qty

TA-T4-03

800-1210mm
Est. Qty

Compatible Components

Enhance your ultra-high installations with tie-rods, slope correctors, and robust accessories for maximum safety.

Joist Cradle
Joist Cradle

Mainly used for the connection and fixation of wooden floor joists and aluminum alloy joists. Optional sizes: 30-80mm, 40mm, 60mm.

Est. Qty
Spacer Tabs
Spacer Tabs

Leaves seams on the stone to allow quick drainage on the stone surface. Available sizes: 2mm, 3mm, 4mm, 5mm, 8mm, 10mm.

Est. Qty
Rubber Shim
Rubber Shim

Thickness 1.5mm. Increases friction between stone and supporter, adjusts uneven thickness, and reduces noise.

Est. Qty
Base Rubber Pad
Base Rubber Pad

Thickness 4.2mm, diameter 210mm. Placed on the bottom of the supporter to prevent sliding, reduce vibration and noise.

Est. Qty
Slope Corrector
Slope Corrector

Suitable for a base diameter of 200mm, the slope can be adjusted from 0% to 5% by turning the slope plate.

Est. Qty
Vertical Closure Clips
Vertical Closure Clips

Stainless steel clips placed at top/bottom. Effectively prevents sliding caused by natural wind or human factors.

Est. Qty
Stainless Perimeter Spacer
Stainless Perimeter Spacer

Engineered to create space between a raised floor and the walls of a building. Absorbs shock and prevents damage.

Est. Qty
Adjustment Key
Adjustment Key

Made of iron, used for effortlessly adjusting the height of TA-V self-leveling pedestal after installation.

Est. Qty
Metal Tile Spacers
Metal Tile Spacers

Heavy-duty metal spacer tabs. Thickness: 4mm.

Est. Qty

Secure Your Extreme Elevations

Ensure absolute safety and flawless execution for your high-span projects. Use our calculator or consult our factory engineers directly.

Online Pedestal Calculator
